Support Beidou-2 and Beidou-3

Support B1I/B1C frequency points

Support B1I or B1C independent positioning

Support A-BDS

Cold start capture sensitivity

-148dBm: hot start capture sensitivity

-156dBm

Re capture sensitivity

-160dBm

Tracking sensitivity

-162dBm

positioning accuracy

2m(CEP50)

First positioning time

≤ 23 seconds

power consumption

Continuous operation ≤ 42mA: standby power consumption

≤ 10uA: Built in LNA, built-in antenna detection and antenna short circuit protection function

Paired with 25x25x4mm high-performance ceramic antenna

Onboard Farad capacitors can achieve fast hot start (<1s hot start)

Standard NMEA-0183 protocol output

signal reception	Beidou-2 and Beidou-3
frequency band support	BDS:B1I, B1C
Cold start TTFF	≤23s
Hot start TTFF	≤1s
Re capture TTFF	≤Is
Cold start capture sensitivity	-148dBm
Hot start capture sensitivity	-156dBm
Re capture sensitivity	-160dBm
Tracking sensitivity	-162dBm
positioning accuracy	≤2m(CEP50)
Speed measurement accuracy	≤0.Im/s (1o)
Positioning update rate	1Hz(默认)最大10Hz
Serial port characteristics	Baud rate: default 115200bps, 8 data bits, no checksum, 1 stop bit
Serial port protocol	NMEA0183
power supply	3.3V - 5.5V
typical power consumption	42mA @5V
Operating Temperature	-40°C to +85 °C
Storage temperature	-50°C to +125°C
size	28x28x7mm
