Support Beidou-2 and Beidou-3;

Supports B1I/B1C/B2I/B3I/B2a/B2b frequency points;

Support A-BDS;

Cold start capture sensitivity: -148dBm;

Hot start capture sensitivity: -156dBm;

Re capture sensitivity: -160dBm;

Tracking sensitivity: -162dBm;

Positioning accuracy: 1m (CEP50);

Initial positioning time: ≤ 20 seconds;

Power consumption: continuous operation~30mA; standby power consumption: ≤ 30uA;

Built in LNA, built-in antenna detection and antenna short circuit protection function;

Paired with 25 * 25 * 4mm stacked 35x35x4mm high-performance ceramic antenna;

Onboard Farad capacitors can achieve fast hot start (<1.5s hot start);

Standard NMEA-0183 protocol output.
